Cargo Door Seals

Product Overview

Cargo Door Security Labels are used as an added layer of security for sealing the doors on truck trailers, sea containers and crates. These seals are applied over the door hinges or across the center gap of the two hinged doors.

Cargo Door Seals

Cargo Door Seals

When removed, the seals will self destruct to indicate tampering, which leaves the OPENED VOID message in the film and a corresponding message in the adhesive residue on the door surface.

Cargo Door Seals are available in stock and custom versions. We also offer matching numbers in sets of 2 or 3 seals -- all having the same number. We provide matching number sets on the same roll and in sequential order.

Choosing A Cargo Door Seal

All seals are suitable for use outdoors.

All of our cargo door seals offer a premium adhesive which can be applied in cold weather -- as low as +10°.

After application, the premium adhesive is rated for service temperatures as low as -40° and up to 200°.

Our large-size seals offer more security because they are more difficult to remove without tampering.

Our premium seals feature serial numbers which are embedded (or laminated), which are more durable for extended outdoor exposure (minimum 1 year life) and are not as susceptible to potential alterations.

Our premium seals also feature "v" security slits for added sensitivity to tampering.

Our premium seals include a perforation on the paper backer (between labels) for ease of use.

Our economy seals feature serial number which are surface printed. These are suitable for outdoor exposure of at least 90 days. The economy seals exclude the "v" security slits and are not perforated.

Custom imprinted seals offer more security.

As an option, we offer non-residue seals to eliminate the need for time-consuming clean up of the adhesive residue. Please call for more information.

Features & Applications

A typical application is to apply the adhesive seal across the center gap of the two hinged doors (see Figure 1). In this application, the seal serves as the primary security seal, or as a secondary layer of protection to the shackle seal (typically a bolt seal, cable seal, barrier seal, etc).

Another application is to apply the adhesive seal over the gap on the hinged doors with one seal on each hinged door (see Figure 2). For high security applications, determined thieves will remove the set of hinged doors at the hinges without removing the security seals on the shackle or on the keeper bars. Applying a security seal from the door to frames protects the doors from removal.

Cargo Door Seals

Cargo Door Seals

Our premium seals include addtional "v" die cuts which promote tearing of the film, which is another measure of tamper evidence.

All stock seals feature a unique serial number in black ink. For the premium seals, the serial number is embedded under the film for added durablility and to combat alterations.

All of uur Cargo Door Seals feature a premium outdoor adhesive, suitable for applying in cold weather.

For added security, our Cargo Door Security Labels can be custom manufactured with your company's text imprint or logo. The hidden tampering message can be customized too. Customizations include any language or copy to make the removal or manipulation of the seal easily understandable in any locale.

Installation Instructions

When affixing, the surface temperature must be a minimum +10°. After application,, the seal is suitable for outdoor temperatures ranging from -40° to +200°.

Clean the surface to remove dirt, grime, grease and contaminants before affixing. The surface must be dry.

Seals are hand-applied. Peel the label from the paper-backing and affix the film to the surface.

Cleaning Up Adhesive Residue

For bare metal surfaces, you can use acetone, iso-propyl alcohol or other aggressive solvents. If the surface is painted, use iso-propyl alcohol or another mild solvent. Read the solvent label for safety procedures.

Specifications & Intended Use

Intended use as a tamper evident label on the doors of trailers or containers. Also suitable for use on wooden crates, cardboard, or other containers.

All seals are constructed of durable polyester film (.002 inches thick) and with an outdoor-grade adhesive.

For more specifications, see the "Specifications" Scroll Down Bar under each product.

Stock Premium Cargo Door Seals

When removed, indicates tampering by showing OPEN VOID in the film; also leaves corresponding adhesive residue on the surface. Also includes these features:

  • Premium adhesive for cold weather application
  • Tamper Slits in the film for added security
  • Perforation between labels for ease of use
  • Serial number (0.25 inch high) is embedded under the film (or laminated) for minimum 1 year outdoor life

Cargo Door Seal, Red, 4 in x 13 in, Roll of 100, XD55-67RE

Cargo Door Seal

Available as a roll of 100 labels with unique serial numbers, these cargo door seals help prevent pilferage of cargo stored in truck trailers, sea containers, and crates. Each label is 4 in x 13 in wide.

Ready To Ship: 1 Business Day

View Video

Add to Cart Code: XD55-67RE

Pricing Information
Qty (Seals) Qty (Rolls) $/Seal $/Roll Total
100 1 $1.59 $159 $159
1,000 10 $1.51 $151 $1,510
5,000 50 Call Call Call
Specifications
Code XD55-67RE
Size 4 in x 13 in
Serial Number Location Embeded Under Film
Color Red
Imprint Color Black
Perforated Between Each Label
Security Features
  • High Residue Adhesive Forumla
  • Tamper Evident
  • Perforated Cuts

Cargo Door Seal, Red, 4 in x 13 in, Matching Sets of 2 Labels Roll of 200, XD55-67RE-MS2

Cargo Door Seal

Cargo Door Seal

Sets of 2 Matching Seals

Available as matching sets of 2 labels with unique serial numbers, these cargo door seals help prevent pilferage of cargo stored in truck trailers, sea containers, and crates. Each label is 4 in x 13 in wide.

Ready To Ship: 1 Business Day

View Video

Add to Cart Code: XD55-67RE-MS2

Pricing Information
Qty (Seals) Qty (Sets of 2) Qty (Rolls) $/Seal $/Roll Total
200 100 1 $1.59 $318 $318
2,000 1,000 10 $1.51 $302 $3,020
10,000 5,000 50 Call Call Call
Specifications
Code XD55-67RE-MS2
Size 4 in x 13 in
Serial Number Location Embeded Under Film
Color Red
Imprint Color Black
Perforated Between Each Label
Security Features
  • High Residue Adhesive Forumla
  • Tamper Evident
  • Perforated Cuts

Cargo Door Seal, Red, 4 in x 13 in, Matching Sets of 3 Labels Roll of 300, XD55-67RE-MS3

Cargo Door Seal

Cargo Door Seal

Cargo Door Seal

Sets of 3 Matching Seals

Available as matching sets of 3 labels with unique serial numbers, these cargo door seals help prevent pilferage of cargo stored in truck trailers, sea containers, and crates. Each label is 4 in x 13 in wide.

Ready To Ship: 1 Business Day

View Video

Add to Cart Code: XD55-67RE-MS3

Pricing Information
Qty (Seals) Qty (Sets of 3) Qty (Rolls) $/Seal $/Roll Total
300 100 1 $1.59 $477 $477
3,000 1,000 10 $1.51 $453 $4,530
15,000 5,000 50 Call Call Call
Specifications
Code XD55-67RE-MS3
Size 4 in x 13 in
Serial Number Location Embeded Under Film
Color Red
Imprint Color Black
Perforated Between Each Label
Security Features
  • High Residue Adhesive Forumla
  • Tamper Evident
  • Perforated Cuts

Stock Economy Cargo Door Seals

Our stock cargo door seals are available for immediate shipment -- your order ships the next business day.

Each seal has a unique pre-assigned serial number, which is surface-printed and suitable for outdoor environments for up to at least 90 days; the seals feature the premium adhesive for cold weather application.

When removed, the seal indicates tampering by showing OPEN VOID in the film and also leaves corresponding adhesive residue on the surface. The adhesive is low residue, which is easier for clean up.

Cargo Door Seals, Red, 4 in x 13 in, Roll of 50, XSTO12-67REAASN-50

Cargo Door Seal

Available as a roll of 50 labels with unique serial numbers; each label is 4 in x 13 in wide.

Ready To Ship: 1 Business Day

View Video

Add to Cart Code: XSTO12-67REAASN-50

Pricing Information
Qty (Seals) Qty (Rolls) $/Seal $/Roll Total
50 1 $0.80 $40 $40
250 5 $0.76 $38 $190
500 10 Call Call Call
Specifications
Code XSTO12-67REAASN-50
Size 4 in x 13 in
Serial Number Location Embeded Under Film
Color Red
Imprint Color Black
Perforated No
Security Features
  • High Residue Adhesive Forumla
  • Tamper Evident

Custom Premium Laminated Cargo Door Seals

As an option, we offer laminated custom printed cargo door seals with your custom text, logo and serial number in black ink. When removed, indicates tampering by showing OPEN VOID in film, and leaves a corresponding adhesive residue on the surface. Also includes these features:

  • Premium adhesive for cold weather application
  • Tamper Slits ("V") in the film for added security
  • Perforation between labels for ease of use

Stock seals have a red background and the stock hidden tamper evident pattern. Seals are available in unique serial numbers or any number of matching number sets. The custom print and serial number are laminated for added durability.

Optional Stock Background Color: Blue, Yellow, Green (please call for pricing)

Optional Custom Colors: Any PMS color (please call for pricing)

Custom Premium Cargo Door Seal, Red, 4 in x 12.5 in, D65-182RE

Custom Cargo Door Seal

Ready To Ship: 2-4 Weeks

Label Size: 4 inch x 12.5 inch

Code: D65-182RE

View Video

Pricing Information
Pricing Formula $300 Setup/Order + $1.59/Seal
Artwork Prep (One-Time) $135
Min Order Qty 500
Different Inks, Hidden Pattern, Etc Call
Typical Order Pricing
Qty (Seals) 500 1,000 5,000
$/Seal $2.46 $2.025 $1.677
Total $1,230 $2,025 $8,385
Specifications
Code D65-182RE
Size 4 in x 12.5 in
Labels/Roll
  • Unique Numbers: 100/Roll
  • Sets of 2: 200/Roll
  • Sets of 3: 300/Roll
Serial Numbers
  • Unique or matching sets of 1, 2 or 3 labels
  • Max 3 in High, Optional Fonts
  • No Duplicate Sets, But May Have Missing Number Sets
Serial Number Location Embeded Under Film
Color Red
Imprint Color Black
Perforated Between Each Label
Security Features
  • High Residue Adhesive Forumla
  • Tamper Evident
  • Perforated Cuts

Custom Economy Cargo Door Seals

As an option, we offer custom printed cargo door seals with your custom text, logo and serial number in black ink. The imprinted text, logo and serial number are surface printed and suitable for outdoor environments for up to at least 90 days.

When removed, indicates tampering by showing OPEN VOID in film, and leaves a corresponding adhesive residue on the surface.

Available in a high residue adhesive (S28-67REAA) or low residue adhesive (STO12-67REAA). The high residue offers more security; the low residue is easier to clean up.

Stock seals have a red background and the stock hidden tamper evident pattern. Seals are available in unique serial numbers or any number of matching number sets.

Optional Stock Background Color: Blue or White (please call for pricing)

Optional Custom Colors: Any PMS color (please call for pricing)

Custom Economy Cargo Door Seal, Red, High Residue, 4 in x 13 in, S28-67REAA

Custom Cargo Door Seal

Ready To Ship: 1-2 Weeks

Label Size: 4 inch x 13 inch

Code: S28-67REAA

Pricing Information
Pricing Formula $50 Setup/Order + $0.90/Seal
Artwork Prep (One-Time) $35
Min Order Qty None
Typical Order Pricing
Qty (Seals) 100 1,000 5,000
$/Seal $1.75 $0.985 $0.917
Total $175 $985 $4,585
Specifications
Code S28-67REAA
Size 4 in x 13 in
Labels/Roll
  • Unique Numbers: 100/Roll
  • Sets of 2: 200/Roll
  • Sets of 3: 300/Roll
Serial Numbers
  • Unique or matching sets of 1, 2 or 3 labels
  • Max 3 in High, Optional Fonts
  • No Duplicate Sets, But May Have Missing Number Sets
Serial Number Location Surface Printed
Color Red
Imprint Color Black
Perforated No
Security Features
  • High Residue Adhesive Forumla
  • Tamper Evident

Custom Economy Cargo Door Seal, Red, Low Residue, 4 in x 13 in, STO12-67REAA

Custom Cargo Door Seal

Ready To Ship: 1-2 Weeks

Label Size: 4 inch x 13 inch

Code: STO12-67REAA

Pricing Information
Pricing Formula $50 Setup/Order + $0.90/Seal
Artwork Prep (One-Time) $35
Min Order Qty None
Typical Order Pricing
Qty (Seals) 100 1,000 5,000
$/Seal $1.75 $0.985 $0.917
Total $175 $985 $4,585
Specifications
Code STO12-67REAA
Size 4 in x 13 in
Labels/Roll
  • Unique Numbers: 100/Roll
  • Sets of 2: 200/Roll
  • Sets of 3: 300/Roll
Serial Numbers
  • Unique or matching sets of 1, 2 or 3 labels
  • Max 3 in High, Optional Fonts
  • No Duplicate Sets, But May Have Missing Number Sets
Serial Number Location Surface Printed
Color Red
Imprint Color Black
Perforated No
Security Features Tamper Evident
